Meet the NEW Breed of Sub-Compact, Hydro-Static Powered MAGNATRAC®! Introducing… B-Series! It’s our least expensive, assembled machine, designed to do TOUGH work in compact spaces. The B-Series will make short work of those homeowner tasks, and save you thousands on contractor bills. Dual zero-turn commercial hydrostatic transaxles, coupled with hydraulic Front and Rear attachments, allow you to accomplish hundreds of back breaking jobs, with only finger tip hydraulic control! Standard contractor grade rubber tracks, make the B-Series the perfect fit for rural or city homeowners. By removing 2 bolts on the optional hydraulic rear hitch, you can switch out most rear mounted attachments in just a few minutes! Accomplish TOUGH projects, such as: moving snow, ripping hard soil, landscaping, pulling logs, digging out stumps and more
The MAGNATRAC® B-Series is the perfect balance of size, price and versatility for homeowners. Save thousands on contractor bills by doing the TOUGH jobs yourself! Sub-Compact bulldozer power allows you to grade driveways, plow snow, pull logs, make a small garden, landscape your yard, make ATV and hiking trails, dig a small fish pond, make food plots and pull 3rd party attachments!
Front options include:
Quick-Attach Front End Loader w/ Bucket
Quick-Attach 2-Way Blade (Power lift, Manual Angle)
Quick-Attach 4-Way Blade (Power lift and Angle)
Quick-Attach 6-Way Blade (Power lift, Angle, and Tilt)
Power Broom
Tiller/Stump Grinder
Bucket mounted Forks
Front-Scoop for Blade
Bucket Mounted Grapple
Rear options include:
Quick-Attach Backhoe w/ 12” Bucket
Quick-Attach Rear Hydro Hitch
3-Shank Ripper
Log Crane
Rock/Debris Thumb
Winch
Ball Hitch Receiver
With the use of our hydraulic rear sleeve hitch system, you can pull other 3rd party attachments like: tillers, moldboard plows, wagons, cargo carriers, trailers, boats etc.
Built for hard work, the Vanguard 40T8 boasts a large capacity, multi-chamber exhaust system, forged steel crankshaft and rigid crankcase helical cut gears, and a sophisticated air intake system. The materials are used to provide years of service with cast iron cylinder sleeve, high quality materials and excellent fit and finish.
These mid-sized Commercial Transaxles perform tough work in tight spaces. We use 2 of them in each B-Series. It starts with a strong, high-efficiency 12cc pump, 16cc motor, and a sturdy 1-1/8” axle shaft. This reliable & quiet drive system, coupled with a hardened rear sprocket hub, pushes Struck® “Dozer Power” down to each track.
Travel on any surface! – Rocky terrain, gravel, nice lawns, concrete, blacktop, etc. Will not scratch driveways or garage floors! These “Contractor Grade” rubber tracks will give you the Power & Traction you’re looking for in a MAGNATRAC®, but with the “Velvet Touch” of Rubber! Rubber tracks consist of a continuous steel core band, forged steel metal bars, and molded grousers.
Smartly designed hydraulic power system, that allows you to effortlessly operate your front and rear hydraulic attachments, with only finger-tip pressure! Includes: 3 or 5 bank valve with cover, hydraulic oil tank with storage area, breather cap, strainer filter, and a 3.3 GPM attachment pump!
Standard options on the MAGNATRAC® B-Series Includes large, bright LED headlight, engine oil drain hose, and a Hour & Tach Meter.
Are mud, snow and hilly terrain on your property? If so, this center idler upgrade is the utmost in track stability and guidance. Upgrade includes: idler mounting frames, (2) 4″ center idlers per side with replaceable oilite bushings, and greaseable quick release axles with submerged grease zerks.
Many other companies make “garden type” implements/attachments that make the MAGNATRAC® B-Series even more versatile. Please speak with a Struck Representative to verify specs on specific third party attachments will be compatible with our equipment. Moldboard plow shown in the picture.
Products to fit the HRH35 – Hydraulic Rear Sleeve Hitch:
